SingleVario 2061

The most flexible parker for retrofitting

SingleVario 2061 – Double decker garage made easy.

The SingleVario 2061 is the simple and inexpensive way to turn one parking space into two – right on top of one another. The premium parker is installed without a pit and is extremely flexible. It can be adapted to the space available and different vehicle heights, for example. This means that additional parking spaces can be created in existing buildings.

As is usual for dependent parking, the lower parking space must be empty before the platform for the second car can be lowered. The system is therefore ideal for using the upper platform for the long-term parking of vintage cars or the like, for example, and the lower parking space for short-term parking.

Specification

For dependent parking

Single platform (SP) for 2 cars

Total height of standard type: 330 cm

Pit depth: no pit required

Vehicle dimensions: height 150 cm to 200 cm

Vehicle dimensions: length 500 cm to 520 cm

Distance between platforms can be adjusted even retrospectively

Usable platform width (EB): 230 cm, optional up to max 270 cm

Standard design: 2,000 kg for the upper parking space

Optional design: 2,600 kg for the upper parking space

No weight restriction for the lower parking space

Horizontal access to the parking level

Retrofitting possible, depending on local conditions

 Platform coating StandardGrip

 Platform coating optional AluLongLife or EasyWalk

Product variants :

1/6

Downloads

Field of Application

 In garages for family homes and apartment buildings

 In office buildings or residential and commercial buildings

 To increase capacity in underground car parks or

 To increase capacity in parking garages, e.g. of hotels, car rentals

 Retrofitting in existing buildings also possible

 Can also be used as an outdoor parking system without a garage, e.g. installation in an inner courtyard or a front garden
